What are the differences in quality testing between new SF6 gas and recycled SF6 gas?
The quality testing of new SF6 gas and recycled (or reclaimed) SF6 gas differs significantly in scope, stringency, and purpose due to their distinct origins and potential contamination levels. Both must meet safety and performance standards before being used in electrical equipment—but the pathways to verification are not the same.
Below is a detailed comparison of the key differences in quality testing between new and recycled SF6 gas:
1. Source and Expected Purity
| Aspect | New SF6 Gas | Recycled SF6 Gas |
|---|---|---|
| Source | Factory-produced, sealed in certified cylinders | Recovered from electrical equipment after use |
| Expected Purity | Very high (≥99.9%) | Variable—depends on recovery process and prior use |
| Typical Contaminants | Minimal; mainly trace air or moisture from packaging | Moisture, air, oil, arc byproducts (SO₂, HF, CF₄, etc.) |
2. Applicable Standards
- New SF6: Must comply with IEC 60376 (International) or ASTM D2472 (North America)—these define strict limits for purity, moisture, acidity, and other impurities.
- Recycled SF6: Should meet IEC 60480 guidelines, which specify acceptable limits for reuse in electrical equipment after reprocessing. Some utilities apply even stricter internal standards.
3. Required Test Parameters
✅ New SF6 Gas – Basic Testing
Testing focuses on verifying manufacturer claims:
- Purity (SF6 concentration): ≥99.9%
- Moisture (H₂O): ≤8 ppmv (dew point ≤ −40°C)
- Air (N₂ + O₂): ≤0.05%
- Mineral oil: ≤10 µg/g
- Acidity (as HF): ≤0.3 µg/g
- CF₄: ≤0.05% (optional, depending on spec)
Often verified via Certificate of Conformity; on-site spot-checks may suffice.
✅ Recycled SF6 Gas – Comprehensive Testing
Must be tested for all new-gas parameters PLUS decomposition byproducts:
- All new-gas tests (purity, moisture, air, oil, acidity)
- Decomposition products:
- SO₂: ≤1 ppmv (indicator of thermal/electrical faults)
- HF: ≤1 ppmv (highly corrosive)
- SOF₂, SOF₄, CF₄, CO, etc. (depending on fault history)
- Toxicity screening (in some cases)
- Particle content (if filtered improperly)
Requires full laboratory or advanced field analysis before reuse.
4. Testing Methods & Equipment
| Parameter | New SF6 | Recycled SF6 |
|---|---|---|
| Purity | IR sensor, GC | GC, FTIR, or multi-gas analyzer |
| Moisture | Chilled mirror hygrometer | Same, but more critical |
| Decomposition Products | Not typically tested | Electrochemical sensors, FTIR, GC-MS |
| On-Site Feasibility | Simple handheld analyzers OK | Often requires lab or high-end portable systems (e.g., DILO 3-033-R022, WIKA GA-20) |
5. Purpose of Testing
- New SF6: Confirm compliance with supply specifications; prevent introduction of substandard gas.
- Recycled SF6: Ensure hazardous byproducts are removed, moisture is reduced, and gas is safe for reintroduction into live equipment without risking insulation failure or personnel exposure.
6. Handling & Documentation
- New SF6: Comes with a Certificate of Quality from the manufacturer.
- Recycled SF6: Requires a post-reclamation test report showing all IEC 60480 parameters are met. Many utilities log gas batches for traceability.
Key Takeaway
New SF6 testing is about verification; recycled SF6 testing is about validation and decontamination assurance.
While new gas is assumed clean and only spot-checked, recycled gas is presumed contaminated until proven otherwise through rigorous, multi-parameter analysis.
Practical Tip:
Even if recycled SF6 meets IEC 60480, some high-voltage applications (e.g., GIS in critical substations) may still require it to meet IEC 60376 standards—effectively treating reclaimed gas as “new” after purification. Always follow your utility’s internal gas management policy.
By applying the appropriate testing protocol for each gas type, operators ensure equipment reliability, personnel safety, and regulatory compliance—while supporting SF6 emission reduction goals through responsible recycling.
