RSS-SF6 Diffused infrared SF6 Gas Detector Sensor
RSS-SF6 Diffused infrared SF6 Gas Detector Sensor
| Category | Details |
|---|---|
| Product Model | RSS-SF6 |
| Product Name | Diffusion-type Infrared Sulfur Hexafluoride Sensor |
| Detected Gas | SF₆ |
| Device Measurement Range | (0~1000) μL/L, (0~1500) μL/L |
| Response Time | Less than 40 seconds |
| Linear Error | ±2% F.S |
The RSS-SF6 diffusion-type infrared sulfur hexafluoride sensor is specifically designed for accurate detection of SF₆ gas. The device has selectable measurement ranges of (0~1000) μL/L or (0~1500) μL/L. The response time is less than 40 seconds, and the linear error is controlled within ±2% F.S, ensuring fast and accurate data. This sensor adopts high-end infrared light sources and pyroelectric detectors, and is equipped with a gold-plated optical path channel to achieve high precision and stability. With the temperature and pressure compensation technology, it can work stably even in harsh environments. Compared with traditional electrochemical sensors, it has no obvious consumption during use, and its service life is more than 10 years, providing long-term and reliable guarantee for the monitoring of SF₆ concentration.
Product Features
- High precision and stability: It adopts high-end infrared light sources and pyroelectric detectors, and selects gold-plated devices as the optical path channel.
- Large-range monitoring: Its good selectivity makes up for the deficiency of traditional electrochemical sensors in the selection of high-range measurement ranges.
- No fear of harsh environments: With the temperature and pressure compensation technology, stable and reliable measurement results can be obtained even under harsh temperature and environmental conditions.
- Long service life: Compared with traditional electrochemical sensors, there is no obvious consumption during use, and the service life is more than 10 years.
Product Parameters
| Parameter Name | Parameter Value |
|---|---|
| Detected Gas | SF₆ |
| Measurement Range | (0~1000)μL/L, (0~1500)μL/L |
| Preheating Time | Less than 2 minutes (preheating time) |
| Linear Error | ±2%F.S |
| Response Time | Less than 40 seconds |
| Repeatability | Less than 1% |
| Minimum Detection Limit | 1%F.S |
| Resolution | 0.1%F.S |
| Operating Voltage | (3.3~6.5V) VDC |
| Operating Current | Maximum 190mA (average 90mA);@5VDC |
| Average Power | Less than 0.7W |
| Peak Power | Less than 1W |
| Signal Output Mode | UART TTL, RS-485 |
| Signal Output Protocol | Modbus ASCII, Modbus RTU |
| Temperature Compensation Range | (-10~40)℃ |
| Operating Humidity | (0~95)%RH (no condensation) |
| Storage Temperature | (-20~60)℃ |
| Pipeline Pressure Compensation Range | (80~110)kPa |
| Dimension | 66mm*36mm *29.5mm(L*W*H） |
| Weight | 36.5g |
