SF6 Gas Recovery, Purification And Detection Device
SF6 Gas Recovery, Purification And Detection Device
| Parameter Name | Parameter Value |
| Product Name | Twin-tower Distillation SF6 Gas Recovery, Purification and Detection Device |
| Recovery Rate | 38 m³/h |
| Negative Pressure Recovery Rate | 31.3 m³/h |
| Vacuum Pumping Rate | 64 m³/h |
| Purification Capacity Compliance | GB/T 12022 |
The twin-tower distillation SF6 gas recovery, purification and detection device is mainly composed of a recovery system, a vacuum pumping system, a gas recharging system, a purification treatment system, a software management system and a gas quality detection system. The purified SF6 gas can meet the cyclic reuse of electrical equipment, reduce the emission of greenhouse gases and save the cost of gas consumption.
The dedicated software management system designed according to the requirements of “decentralized recovery and unified management” of the power grid can uniformly manage, store and analyze the data of the gas quality on site.
The full-function recovery, purification treatment and gas detection device is an ideal device for on-site emergency, repair and recovery, and purification treatment of SF6 gas in electrical equipment. The first electrically driven self-loading purification system，and the quality of the treated gas meets the requirements of new gas in GB/T12022-2014. The whole vehicle complies with IEC and EU standards.
Functional Features
SF6 gas recovery, purification and storage, and the quality of the purified SF6 gas meets the requirements of the GB/T 12022 standard;
The SF6 gas recovery, purification and detection device can recharge the purified SF6 gas into switchgear or pressure vessels;
It can filter impurities such as moisture, decomposition products and solid particles in the SF6 gas;
It can evacuate itself and external equipment, and detect and display the vacuum degree in real time;
The lifting distillation tower can improve the quality of gas purification;
It has a negative pressure recovery function to improve the recovery rate;
The vacuum pump is equipped with an anti-oil return valve to prevent oil return;
The SF6 gas recovery, purification and detection device is equipped with an independent distillation tank and a gas heating system to improve the recharging efficiency;
It has the function of SF6 liquid filling, and it can fill a 40 L steel cylinder with 50 kg of SF6 within (5~8) minutes;
The SF6 gas recovery, purification and detection device adopts an industrial control system and is operated via a touch screen throughout the process;
Optional embedded detection instruments can detect the purity, humidity and decomposition products of SF6 gas.
Product Parameters
| Parameter Name | Parameter Value |
| Recovery Rate | 38 m³/h |
| Negative Pressure Recovery Rate | 31.3 m³/h |
| Vacuum Pumping Rate | 64 m³/h |
| Purification Capacity | Comply with GB/T 12022 |
| Power Supply | AC380 V, 50 Hz |
| Storage Tank Volume | 300 L |
| Filling Rate | (375~600) kg/h |
| Ultimate Vacuum Degree | ≤10 Pa |
| Annual Leakage Rate | ≤1 % |
| Power | 28 kW |
